Wanting to overnight, what anchor?

Mar 8, 2011
296
Ranger 33 Norfolk
New Rocna 15 came into today, and boy is she purttee ;) And monstrous! That 22lb fluke doesn't look good enough for a dink next to this baby! I bought 150' of 3 strand nylon 5/8" from Salty Dogs. Next is 50 ft of 5/16" g-4 or 3/8" g-3. . .


Gunni

.
Mar 16, 2010
5,937
Beneteau 411 Oceanis Annapolis
Excellent! How are you planning to splice your rope to chain? Here is a link to the back-tapered splice. Easy with 3-strand.

Jul 1, 1998
3,062
Hunter Legend 35 Poulsbo/Semiahmoo WA
A rode is as strong as it's weakest link

You've got a good anchor and you're looking at some good chain. If you use a shackle somewhere in the system, say the chain to anchor connection for example, be sure to get a GOOD shackle.

If there is a place that carries gear for weight lifting they should have rated shackles. West Marine, several years ago, switched from their "Made in China" supplier to "Made in Japan" because of concerns about quality of the steel.

In the scheme of things, the shackle is the "nickel/dime item" but very important.

A little research on weight lifting gear might be an idea. OSHA has some requirements - haven't checked them in years, though.

"The devil is in the details"

Jan 22, 2008
1,483
Hunter 37 C sloop Punta Gorda FL
You've got a good anchor and you're looking at some good chain. If you use a shackle somewhere in the system, say the chain to anchor connection for example, be sure to get a GOOD shackle. If there is a place that carries gear for weight lifting they should have rated shackles. West Marine, several years ago, switched from their "Made in China" supplier to "Made in Japan" because of concerns about quality of the steel. In the scheme of things, the shackle is the "nickel/dime item" but very important. A little research on weight lifting gear might be an idea. OSHA has some requirements - haven't checked them in years, though. "The devil is in the details"
Defender and Jamestown distributors carry "rated shackles. I'd. Bet a bundle that SBO does also.

Mar 8, 2011
296
Ranger 33 Norfolk
Defender has chain at a good price as well as Crosby shackles. The 3/8" G-209A has a WLL of 4410 lbs and a Ultimate Strength of 19845 lbs. I can't find anything bigger that will fit into the chain. I think I'll get the Acco 5/16" G-4 and 2 shackles on order tomorrow. Capn' Mike of Salty Dog spliced a thimble into one end of the rode for me since I don't have a windlass. The video was informative to watch though.

All said and done this is running around $800 (glad I'm working OT this week) :cry: Anchoring out better be the best thing since sliced bread, lol :dance:

Jan 22, 2008
8,050
Beneteau 323 Annapolis MD
Defender has chain at a good price as well as Crosby shackles. The 3/8" G-209A has a WLL of 4410 lbs and a Ultimate Strength of 19845 lbs. I can't find anything bigger that will fit into the chain. I think I'll get the Acco 5/16" G-4 and 2 shackles on order tomorrow. Capn' Mike of Salty Dog spliced a thimble into one end of the rode for me since I don't have a windlass. The video was informative to watch though.

All said and done this is running around $800 (glad I'm working OT this week) :cry: Anchoring out better be the best thing since sliced bread, lol :dance:
Did you look at Baconsails.com (Annapolis)for the chain?

Jul 1, 1998
3,062
Hunter Legend 35 Poulsbo/Semiahmoo WA
Weighing Anchor, The other part of anchoring

Thinking a little more about your anchor test, since you're using the Armstrong method, if the test involves a muddy bottom and a good load (wind & current), when you go to weigh anchor it will probably (hopefully) take a lot of work.

With the anchor being, what, about 35 pounds, and the chain being probably around 50 feet, that will be a bit of weight. Plus, the pull of the anchor against the mud or what ever it is buried in.

A good plan is to bring in as much rode as the Armstrong method feels it wants to handle and at that point the bow is setting close to over where the anchor is. Go back to the cockpit and rest for a bit and let the boat bob in the water on whatever waves might be available. After a bit of a wait, then go back and give it another go then hopefully the anchor comes up.

What if it doesn't and it's stubborn? run a line from the rode, probably tied off to the chain, aft to the primary in the cockpit. Use something like a snatch block on a perforated toe rail to give it a fairlead, then use the winch to take up the slack. This should bring the anchor up unless it is snagged on something.

Years ago I went out to bring up a turning mark that was used in a race and really struggled bringing it up. It was snagged on an abandoned crab trap. Yuk! Around our area there are a lot of old log booming grounds in some of the better anchorages and it's been known to snag a submerged cable (log boom were held together with cables). With a popular anchorage, though, hopefully all the surprises have been found. Oh, and check the chart for cables.

Hopefully you enjoy your anchoring test!

Mar 1, 2012
2,182
1961 Rhodes Meridian 25 Texas coast
A few years ago I was tied to the bulkhead in Mandeville, La. Had a 4 pound Danforth out abeam to keep the wakes from bouncing us off the bulkhead. Came time to leave, I freed us from the bulkhead, drifted out over the 4 pounder and it refused to come up. I wrapped the line around a boat cushion and heaved. I was getting laughed at- "hey- it's just a 4 pound anchor!!":confused:

It finally began to move, slowly, then a bit faster. then it broke the surface-

Hooked right in the center of a set of mattress springs, dripping mud. And covered with Mardi Gras bead strands!!:eek:

Turns out a house boat had been destroyed there by a hurricane a few years earlier. Talk about a SEA ANCHOR!!:D

Sep 15, 2009
6,243
S2 9.2a Fairhope Al
A few years ago I was tied to the bulkhead in Mandeville, La. Had a 4 pound Danforth out abeam to keep the wakes from bouncing us off the bulkhead. Came time to leave, I freed us from the bulkhead, drifted out over the 4 pounder and it refused to come up. I wrapped the line around a boat cushion and heaved. I was getting laughed at- "hey- it's just a 4 pound anchor!!":confused:

It finally began to move, slowly, then a bit faster. then it broke the surface-

Hooked right in the center of a set of mattress springs, dripping mud. And covered with Mardi Gras bead strands!!:eek:

Turns out a house boat had been destroyed there by a hurricane a few years earlier. Talk about a SEA ANCHOR!!:D
was it Sealy or Simmons is the question :D


CarlN

.
Jan 4, 2009
603
Ketch 55 Bristol, RI
Believe me, when a thunderstorm wakes you up at 2AM you are going to be very happy to be on that Rocna instead of the SeaChoice.

Be sure to mark your rode so you know how much scope you have out. One of the easiest systems are color plastic wire ties stuck through the line. A blue tie for each 50ft and a red tie for each ten is one example. No need to mark the first 50 feet (50 ft is 5:1 scope in 7ft water and 3ft bow height). Remember to plan your scope for high tide. Most of the time, you'll be letting out 80ft - 120ft. Don't go less than 5:1 scope.

You are going to be surprised how much rode you need to let out.

Before dropping the anchor, think about how you (and the other boats) will swing when the wind or current changes. One good plan in a crowded anchorage is to drop your anchor 2-3 boat lengths directly behind another anchored boat that doesn't have a boat near its stern. After dropping back on your line you won't feel too close but a later boat won't (hopefully) anchor between you.

When anchoring always go bow into the wind or current (whichever is stronger). Use the engine to stop the boat dead. Lower the anchor and then let the boat drift back letting the line pay out as you go. Snub the line at the right scope. You'll see the line and chain stretch out tight as the anchor digs in, then sag a bit. Cleat the line. Then put the engine in slow reverse and wait until the anchor line goes "bar" tight with the engine still in reverse. "Bar tight" is only a few hundred pounds of tension (if your reverse isn't strong, add some RPM).

There will be no doubt in your mind when you're set. That Rocna will feel like you're tied to a pier :D If the line doesn't go tight, pull up the anchor and try again 50ft one direction or another. About one in five times, I decide that I don't like my position after anchoring -- I'm too near another boat or too close to a mud bank if the wind changes. In that case, I always pull up the anchor and move to another spot. What's inconvenient at 5PM is a very scary at 2AM.

If you have a smartphone, get an anchor watch app. Set it as you drop the anchor. That way when you swing you'll still show the same distance from the anchor. If the distance gets bigger, you're dragging.

Mar 8, 2011
296
Ranger 33 Norfolk
ok! Everything is in and I think I'm ready to go. . .this weekend should be nice. Hopefully everything works out and I can head over to Willoughby Bay, set the hook, and just relax.

Thanks all for the help! Oh, what about anchor bouys? I have some that are used as fenders, what size line should I use to tie off?


Gunni

.
Mar 16, 2010
5,937
Beneteau 411 Oceanis Annapolis
3/8 line will work (old furling line). But if the anchorage is not crowded I wouldn't bother, that is a nice sandy bottom you'll have no problem retrieving your precious hook. Enjoy!

Feb 26, 2004
23,019
Catalina 34 224 Maple Bay, BC, Canada
Thanks all for the help! Oh, what about anchor bouys?
Please don't.

There have been thousands of discussions about this bane of anchoring fields. Do a Google search and read away, I really have no patience for these kind of stunts.

Wanna know how I really feel about it???:eek::eek::eek:

Mar 8, 2011
296
Ranger 33 Norfolk
Just a quick update, I might post another thread with some pics if I get a chance.

Weekend turned out to be a bit windier than NOAA predicted, especially Sunday morning. I woke up around 8 AM ready to cast off so I could get some errands done. . .no such luck. A "Weather Advisory" called for a front to pass through with 20-25 knot winds out of the North till about 11 am then taper off. I'm very glad I bought a new anchor and line. I didn't drag a bit. I'm not sure how I would have fared with the fluke (probably would have been fine, but still).

I left around noon and got to sail back in some (at least to me) gnarly seas. 3-4 foot swells, 15 knots and gusty. That's a lot more than the 5-8 knots and lil' 1 foot lappers I'm used too :doh:

EDIT: I didn't use an anchor buoy, lol

T'was fun none the less. Hope my week off is less demanding but just as exciting!

Aug 1, 2012
25
Catalina 27 Curtice, OH
3-4 foot swells, 15 knots and gusty. That's a lot more than the 5-8 knots and lil' 1 foot lappers I'm used too :doh:
This is us too. We are 3 years into sailing and last year got caught in a storm, which scared us a bit. We haven't anchored yet either, but I think we will this weekend. Thanks for starting this thread; it was just the inspiration I was looking for!

Jun 8, 2004
853
Pearson 26W Marblehead
anchors

Ive got a 16 lb bruce; 30 ft of chain 200 ft of 1/2 " nylon rode. I probably should have a heavier anchor, but I might have a problem hauling it back aboard at 77 162 lbs after having back surgery Im afraid to try anything heavier. I use 6 times scope stay out of open
anchorages and hope for the best
