I have an Oday 20 A previous owner installed a hinged mast step , which helps in stepping then mast. However the angle of the mast is not perpendicular to the boat. It creates a tilt of about 10-15 degrees toward the back. The backstay is never taught and I wonder if this needs to be addressed. I have never seen another 20 from the side perspective and don't know if this is proper. Can anyone help ?
Mast Angle
- Thread starter britt007
- Start date
Might find these threads discussing mast rake and tensioning. I am sure the forum will also have recommendations based on their experience and in particular on an O'Day 20.
www.sailmagazine.com
O'Day 20 Mast Rake
I am (finally) getting our 1976 O'Day 20 ready for launch this season here in Southern New Hampshire. I purchased a new forestay, and am wondering if there is any specific amount the mast should be raked back. Based on what I am seeing with the new forestay, and was also the case with the old...
forums.sailboatowners.com
O'Day 25 mast rake and front/aft stay tension level
Hi all, is there an optimum mast rake (angle) for an O'Day 25 (centerboard)? What is max. tension for fore and aft stays in an O'Day 25.
forums.sailboatowners.com
What Mast Rake is All About
Mast rake is the angle at which a mast slopes aft from vertical as viewed from the side. In the rare event that a mast is raked forward it is said to have
www.sailmagazine.com
Does your forestay reach the top of the mast or does it end 3/4 up the mast? If it goes all the way your mast should be straight both to the sides and front and back. If it ends up 3/4 up the mast then it will likely have some bend aft. 10 to 15 degrees would be quite excessive and no, the backstay should not be slack. If you are getting mast pumping or oscillation stop using the boat until the rigging is properly tensioned. Using a level check the hinged mast step to see if it was properly installed. If it is significantly out of level see if it can be corrected or replaced. Do wait to hear to what other Oday 20 might have to say but in the meantime check a few articles on tuning the standing rigging.
